Davey D40A general purpose dewatering sump pump

• Open impeller centrifugal design reduces blockage susceptibility
• Integrated float switch for automatic operation
• Corrosion-resistant 304 stainless steel motor shell, strainer, handle, and fasteners
• Cast iron pump body, motor top, and impeller for durability
• Automatic resetting thermal overload protection
• Handles soft solids up to 10mm diameter
• Carbon/ceramic mechanical seal for reliable operation
• 10-metre HO7RN-F oil-resistant power cable
• Compact submersible design
• Attractive, long-lasting appearance
• Easy installation with handle for positioning

✓ Sump emptying and dewatering
✓ Basement, cellar, and garage water removal
✓ Septic water disposal
✓ Water transfer applications
✓ Pumping neutral factory waste water
✓ Dewatering ditches, pits, and ponds
✓ Storm water management
✓ Decorative water features
✓ Grey water applications
✓ General water removal tasks

Model: D40A
Motor Power: 400W (0.4kW)
Maximum Flow Rate: 240 litres/minute
Maximum Head: 12 metres
Outlet Size: 2" Female (50mm)
Maximum Submergence: 10 metres
Maximum Operating Temperature: 50°C
Maximum Soft Solid Diameter: 10mm
Voltage: 240V, 50Hz Single Phase
Starting Current: 10.5 amps
Running Current: 3.7 amps
Cable Length: 10 metres HO7RN-F oil-resistant
Float Switch: Automatic operation included
Thermal Protection: Automatic resetting thermal overload
Construction: Cast iron pump body and impeller, 304SS motor shell and strainer
Mechanical Seal: Carbon/ceramic
Pump Shaft: 304 stainless steel
Suitable Fluids: Clean or grey water with neutral pH, up to 10% small soft solids or 1% fine solids
Warranty: 24 months
Weight: 14kg
Dimensions: 220mm x 190mm x 460mm

Download data sheet here
Download the installation guide here
Download the float switch info guide here
